FLD-4050L AC3A
Internal and External API Rotary Shoulder Non-Topping Profile FloLock Threading Inserts w/Left Hand Clamping Notch
| Threads per Inch (TPI) | 4 | Cutting Direction (HAND) | Left Hand |
| Application | | Int Ext Threading Flo Lock | | Thread Pitch Maximum (TPX) | 0.453 mm |
| Insert Thickness (S) | 0.255″ | Insert to Shank Reference | 0.128″ |
| Corner Radius (RE) | 0.0225″ | Cutting Edge Length (L) | 0.629″ |
| Body Material | Carbide | Coating | TiAlN |
| Applicable Material | | Steel | Stainless Steel | Hard Materials | Super-Alloys / Titanium | | Measurement Type | Inch |
| Grade | AC3A | Thread Form Type (THFT) | API Partial Profile |
Product Features
| Family Description | Internal and External API Rotary Shoulder Non-Topping Profile FloLock Threading Inserts w/Left Hand Clamping Notch | Country of Origin | USA |
Shipping Info
Package Weight
0.001
